S220PAICH2A是通用电气公司开发的模拟/0模块。它是Mark Vle Speedtronic控制系统的一部分。这个/0包直接连接到端了板上，I/0组件通过一个DC 37针连接器连接到单工端子板。如果只安装了一个/0包，TMR功能端子板有三个DC-37针连接器，可以在单工模式下使用。所有这些连接都由I/O包直接支持。

功能描述

。模拟1/0组件(PAIC)是一个电气接口，将一个或两个/0以太网连接到模拟输入端子板。PAIC包括一个BPPx处理器板和一个专用于模拟I/O功能的采集板

该模块有十个模拟输入。前八个输入可以设置为5 V、10V或4-20 mA电流环路输入。最后两个输入可以设置为1 mA或4-20mA电流输入。

电流回路输入的负载终端电阻位于端子板上，PAIC检测这些电阻上的电压。PAICH2有两个电流环路输出，范围为0至20mA。它还包括额外的硬件，仅允许第一个输出端有0-200 mA电流。

I/O包通过双RJ-45以太网连接器接收和发送数据到控制器，并由一个三针连接器供电。现场设备通过直接连接到相关端子板的DC 37针连接器进行通信。LED指示灯提供视觉诊断。

IS220PAICH2A 336A4940CSP11 模拟输入模块

S220PAICH2A is an analog /0 module developed by General Electric Company. It is a part of Mark Vle Speedtronic control system. This /0 package is directly connected to the terminal board, and the I/0 module is connected to the simplex terminal board through a DC 37-pin connector. If only one /0 package is installed, the TMR function terminal board has three DC-37 pin connectors, which can be used in simplex mode. All these connections are directly supported by I/O packages.

functional description

. Analog 1/0 Module (PAIC) is an electrical interface that connects one or two /0 Ethernet to the analog input terminal board. PAIC includes a BPPx processor board and an acquisition board dedicated to analog I/O functions.

This module has ten analog inputs. The first eight inputs can be set as 5 V, 10V or 4-20 mA current loop inputs. The last two inputs can be set as 1 mA or 4-20mA current inputs.

The load terminal resistors of the current loop input are located on the terminal board, and PAIC detects the voltage on these resistors. PAICH2 has two current loop outputs ranging from 0 to 20mA. It also includes additional hardware, and only the first output terminal is allowed to have 0-200 mA current.

I/O package receives and sends data to the controller through dual RJ-45 Ethernet connectors, and is powered by a three-pin connector. Field devices communicate through DC 37-pin connectors directly connected to the relevant terminal boards. LED indicator provides visual diagnosis.
