TRICONEX 3721 模拟量输入模块

TRICONEX 3721，这是一款由 Triconex（英维思）推出的高可靠性工业控制模块。它属于 Tricon TMR 安全控制系统系列，专为 SIL3 级关键安全场景设计。

 核心定位与通道配置

• 设备类型：TMR（三模冗余）差分模拟量输入模块。
• 通道规格：具备 32 通道差分直流耦合（DC-coupled）输入能力，支持独立配置电压或电流信号。

• 颜色标识：模块外观为黄色。

•


  硬件性能与控制功能

• 高精度采集：支持 0–5V / ±5V 电压信号与 0–20mA 电流信号；分辨率可达 12位/14位可编程，全通道同步刷新速率达 10ms，测量精度极高（< 0.15% FSR）。
• 强抗干扰与隔离：采用三重冗余设计，各通道间电气隔离，具备高共模抑制比和过压保护，适应工业现场的强电磁干扰环境。

• 在线维护：支持热插拔功能，可在线更换模块而不中断系统运行，前面板配备 PASS、FAULT、ACTIVE、FIELD 状态指示灯，便于实时诊断。

•


  通信接口与应用场景

• 系统集成：需配合 Tricon TMR 安全控制系统使用（要求 v10.2 及以上固件），通过 TriStation 软件进行灵活配置。
• 典型应用：广泛应用于石油化工（反应器监测、紧急停车 ESD）、油气开采（井口安全联锁）、电力行业（锅炉安全控制、汽轮机保护）以及火气系统（F&G）等对安全性要求极高的领域。

TRICONEX 3721， This is a high reliability industrial control module launched by Triconex. It belongs to the Tricon TMR safety control system series, designed specifically for SIL3 level critical safety scenarios.

Core positioning and channel configuration

Equipment type: TMR (the third mock examination Redundancy) differential analog input module.

Channel specifications: Equipped with 32 channel differential DC coupled input capability, supporting independent configuration of voltage or current signals.

Color identification: The module appearance is yellow.

Hardware performance and control functions

High precision acquisition: supports 0-5V/± 5V voltage signals and 0-20mA current signals; The resolution can reach 12 bits/14 bits programmable, the full channel synchronous refresh rate can reach 10ms, and the measurement accuracy is extremely high (<0.15% FSR).

Strong anti-interference and isolation: Adopting a triple redundancy design, each channel is electrically isolated, with high common mode rejection ratio and overvoltage protection, suitable for strong electromagnetic interference environments in industrial sites.

Online maintenance: Supports hot swapping function, allowing for online module replacement without interrupting system operation. The front panel is equipped with PASS, FAULT, ACTION, and FILD status indicator lights for real-time diagnosis.

Communication Interface and Application Scenarios

System integration: It needs to be used in conjunction with the Tricon TMR security control system (requiring firmware v10.2 or above), and can be flexibly configured through the TriStation software.

Typical applications: Widely used in industries with high safety requirements such as petrochemicals (reactor monitoring, emergency shutdown ESD), oil and gas extraction (wellhead safety interlocking), power industry (boiler safety control, turbine protection), and fire and gas systems (F&G).
