PPD103-B03-10-150000  中央处理单元

【产品详情】

 PPD103-B03-10-150000  中央处理单元是PLC的控制中枢.它按照PLC系统程序赋予的功能接收并存储从编程器输入的用户程序和数据，检查电源、存储器、I/O以及警戒定时器的状态，并能诊断用户程序中的语法错误:当PLC投入运行时，首先它以扫描的方式接收现场各输入装置的状态和数据，并分别存入IO映像区，然后从用户程序存储器中逐条读取用户程序，经过命令解释后，按指令的规定将逻辑或算术运算的结果送入1O映像区或数据寄存器内。等所有的用户程序执行完毕之后，最后将1/0映像区的各输出状态或输出寄存器内的数据传送到相应的输出装置，如此循环运行，直到停止运行为止。为了进一步提高PLC的可靠性，近年来对大型PLC还采用双CPU构成冗余系统,或采用三CPU的表决式系统。这样，即使某个CPU出现故障，整个系统仍能正常运行。

PPD103-B03-10-150000  中央处理单元

【英文介绍】

 PPD103-B03-10-150000 central processing unit is the control center of PLC. It receives and stores user programs and data input from the programmer according to the function given by the PLC system program, checks the status of power supply, memory, I/O and alarm timer, and can diagnose grammar errors in the user program: When the PLC is put into operation, it first receives the status and data of each input device in the field by scanning, and stores them in the IO image area. Then read the user program one by one from the user program memory, after command interpretation, according to the instructions to the logic or arithmetic operation results into the 1O map area or data register. After all the user programs are executed, the data in each output state or output register in the 1/0 image area is finally transmitted to the corresponding output device, and so the cycle runs until it stops running. In order to further improve the reliability of the PLC, in recent years, the large PLC has also adopted a redundant system with double cpus, or a three-CPU voting system. In this way, even if one CPU fails, the whole system can still run normally.
