CI532V02 3BSE003827R1 | 非冗余模拟量输出底板
产品概述
| 项目 | 详情 |
|---|---|
| 品牌 | ABB |
| 完整型号 | 3BSE003827R1 / CI532V02 |
| 产品类型 | 非冗余模拟量输出底板 / 双通道通信接口子模块 |
| 所属系统 | ABB Advant OCS 控制器系列 |
| 产地 | 瑞士 / 瑞典 |
| HS Code | 853890 |
| WEEE Category | 5 |
核心定位：该模块是 ABB Advant 控制器的非冗余模拟量输出底板，内置 2 通道 RCOM/RCOM+ 通信接口，支持 Modbus 协议，用于连接现场模拟量输出设备（如执行器、变送器等），实现控制器与外部设备的数据交换。
核心功能与特性
| 特性 | 说明 |
|---|---|
| 非冗余设计 | 单通道工作，无冗余备份，适用于对可靠性要求一般的场合 |
| 双通道通信 | 2 通道 RCOM/RCOM+ 接口，支持 Modbus RTU/TCP 协议 |
| 模拟量输出 | 提供模拟量信号输出通道，驱动现场执行机构 |
| 高速传输 | 数据传输速率高，满足实时控制需求 |
| 24V DC 供电 | 标准工业电源，兼容性强 |
| 宽温工作 | 工作温度 -40°C ~ +70°C（部分资料标注 40°C~+70°C） |
| 紧凑尺寸 | 120mm × 80mm × 40mm，节省柜内空间 |
| 即插即用 | 支持热插拔，减少停机维护时间 |
| RoHS 豁免 | 根据 2011/65/EU 指令第 2(4)(c)、(e)、(f)、(j) 条豁免 |
技术规格参数
| 参数 | 规格 |
|---|---|
| 通信协议 | Modbus RTU / Modbus TCP |
| 通信接口 | 2 × RCOM / RCOM+（双通道） |
| 电源电压 | 24 VDC |
| 工作温度 | -40°C ~ +70°C |
| 存储温度 | -40°C ~ +85°C |
| 尺寸 | 120mm × 80mm × 40mm |
| 重量 | 约 0.1~0.3 kg（估） |
| 防护等级 | IP20（柜内安装） |
| 物料号 | 3BSE003827R1 |
| 型号代码 | CI532V02 |
应用领域
| 领域 | 具体应用 |
|---|---|
| 电力系统 | 发电机组辅助控制、励磁系统模拟量输出 |
| 工业自动化 | 过程控制系统中的模拟量信号输出（阀门、挡板控制） |
| 水处理/环保 | 加药系统、流量控制的模拟量输出 |
| 石油化工 | 温度、压力、流量等模拟量信号输出与采集 |
| 楼宇自动化 | BA 系统中的模拟量输出控制 |
关联模块（Advant OCS 系列）
| 物料号 | 型号 | 功能 |
|---|---|---|
| 3BSE003828R1 | CI532V01 | 单通道 RCOM 通信接口 |
| 3BSE003827R1 | CI532V02 | 双通道非冗余模拟量输出底板（本型号） |
| 3BSE003829R1 | CI532V04 | 四通道版本 |
| 3BSE013281R1 | TC514V2 AF100 | Twisted Pair to Opto 转换 |
| 3BSE009598R1 | PM150V08 | 处理器模块 |
| 3BSE018283R1 | CI522A AF100 | 双通道通信接口 |
| 3BSE018293R1 | DSAO120A | 模拟量输出板 |
| 3BSE018295R1 | DSDI110AV1 | 数字量输入板 |
| 3BSE018298R1 | DSDO115A | 数字量输出板 |
CI532V02 3BSE003827R1 | Non redundant analog output backplane
Product Overview
Project Details
Brand ABB
Complete model 3BSE003827R1/CI532V02
Product type: Non redundant analog output board/dual channel communication interface submodule
ABB Advant OCS Controller Series
Origin Switzerland/Sweden
HS Code 853890
WEEE Category 5
Core positioning: This module is a non redundant analog output backplane for ABB Advant controllers, with built-in 2-channel RCOM/RCOM+communication interfaces and support for Modbus protocol. It is used to connect on-site analog output devices (such as actuators, transmitters, etc.) and achieve data exchange between the controller and external devices.
Core functions and features
Characteristic Description
Non redundant design for single channel operation, no redundant backup, suitable for situations with general reliability requirements
Dual channel communication with 2-channel RCOM/RCOM+interface, supporting Modbus RTU/TCP protocol
Analog output provides an analog signal output channel to drive on-site actuators
High speed transmission of data, meeting real-time control requirements
24V DC power supply standard industrial power supply, strong compatibility
Wide temperature working temperature -40 ° C~+70 ° C (some data indicate 40 ° C~+70 ° C)
Compact size 120mm x 80mm x 40mm, saving cabinet space
Plug and play support for hot swapping, reducing downtime for maintenance
RoHS exemptions are granted in accordance with Article 2 (4) (c), (e), (f), and (j) of Directive 2011/65/EU
Technical specifications and parameters
Parameter specifications
Communication Protocol Modbus RTU/Modbus TCP
Communication interface 2 x RCOM/RCOM+(dual channel)
Power supply voltage 24 VDC
Working temperature -40 ° C~+70 ° C
Storage temperature -40 ° C~+85 ° C
Dimensions 120mm × 80mm × 40mm
Weight approximately 0.1~0.3 kg (estimated)
Protection level IP20 (installed inside the cabinet)
Material number 3BSE003827R1
Model code CI532V02
application field
Specific applications in the field
Auxiliary control of power system generator sets and analog output of excitation system
Analog signal output in industrial automation process control system (valve, baffle control)
Analog output of water treatment/environmental dosing system and flow control
Output and acquisition of analog signals such as temperature, pressure, and flow rate in petrochemical industry
Analog Output Control in Building Automation BA System
Association module (Advant OCS series)
Material number, model, and function
3BSE003828R1 CI532V01 Single Channel RCOM Communication Interface
3BSE003827R1 CI532V02 Dual Channel Non Redundant Analog Output Backboard (This Model)
3BSE003829R1 CI532V04 four channel version
3BSE013281R1 TC514V2 AF100 Twisted Pair to Opto Conversion
3BSE009598R1 PM150V08 processor module
3BSE018283R1 CI522A AF100 dual channel communication interface
3BSE018293R1 DSAO120A Analog Output Board
3BSE018295R1 DSDI110AV1 Digital Input Board
3BSE018298R1 DSDO115A Digital Output Board
