UA D215 A104 | 3BHE026284R0104 控制器
产品概述
| 项目 | 详情 |
|---|---|
| 品牌 | ABB |
| 完整型号 | 3BHE026284R0104 / UA D215 A104 |
| 产品类型 | CSI 转换器信号接口板（Converter Signal Interface） |
| 所属系统 | UNITROL 6000 系列静态励磁系统 |
| 电压等级 | 30V, 500V |
| 产地 | 瑞士/美国 |
核心定位：该模块是 ABB UNITROL 6000 励磁系统中的脉冲触发与信号转换核心板卡，负责将控制信号转换为晶闸管/IGBT 的触发脉冲，驱动整流桥输出励磁电流。
核心功能与特性
| 特性 | 说明 |
|---|---|
| CSI 信号转换 | 将控制器输出的数字信号转换为整流桥所需的触发脉冲信号（30V / 500V 等级） |
| 脉冲触发生成 | 集成脉冲触发板（PTB）功能，精确控制晶闸管/IGBT 导通角 |
| 励磁电流闭环控制 | 配合 PID 算法调节发电机转子励磁电流，维持端电压稳定 |
| 系统保护监测 | 实时监测过压、欠压、过流等故障，支持快速保护动作 |
| 双电源冗余 | 支持 DC 9~36V 双电源冗余输入，确保电源故障时持续运行 |
| 热插拔设计 | 支持带电插拔，减少停机时间 |
| 工业级可靠性 | 工作温度 -40°C ~ +75°C，防护等级 IP20 |
| 远程维护 | 支持以太网远程诊断、参数修改与固件升级 |
UA D215 系列完整对照表
| 物料号 | 型号 | 电压等级 | 应用场景 |
|---|---|---|---|
| 3BHE026284R0101 | UA D215 A101 | 15V, 500V | 低压小功率励磁 |
| 3BHE026284R0102 | UA D215 A102 | 15V, 1000V | 中压中等功率 |
| 3BHE026284R0104 | UA D215 A104 | 30V, 500V | ⭐ 本型号（中压标准功率） |
| 3BHE026284R0105 | UA D215 A105 | 30V, 1000V | 高压中等功率 |
| 3BHE026284R0106 | UA D215 A106 | 30V, 1500V | 超高压大功率 |
| 3BHE051993R0001 | Adapter Plate | — | UA D215 → UA D209 适配板 |
应用领域
| 领域 | 具体应用 |
|---|---|
| 火电/水电/核电 | 同步发电机励磁控制，维持机端电压稳定 |
| 工业电机励磁 | 钢铁、造纸、化工等行业大型电机精确励磁控制 |
| 可再生能源 | 风电、光伏并网控制，提升电网灵活性 |
| DCS/SCADA 集成 | 支持 Modbus TCP/IP、Profibus-DP、IEC 61850 等协议 |
关联模块（UNITROL 6000 系统）
| 物料号 | 型号 | 功能 |
|---|---|---|
| 3BHE022291R0101 | PC D230 | 励磁调节器测量板（CCM） |
| 3BHE025541R0101 | PC D231 B | CCI 转换器控制接口 |
| 3BHE041343R0102 | PC D530 A102 | 通信控制测量（标准控制器） |
| 3BHE023784R2030 | PP D113 B01-20 | AC800PEC 控制器 |
| 3BHE023126R0020 | AF D242 A CCP | 变换器控制面板 |
UA D215 A104 | 3BHE02284R0104 Controller
Product Overview
Project Details
Brand ABB
Complete model 3BHE02284R0104/UA D215 A104
Product Type CSI Converter Signal Interface Board
System UNITOL 6000 series static excitation system
Voltage level 30V, 500V
Origin Switzerland/USA
Core positioning: This module is the pulse triggering and signal conversion core board in the ABB UNITOL 6000 excitation system, responsible for converting control signals into trigger pulses for thyristors/IGBTs, driving the rectifier bridge to output excitation current.
Core functions and features
Characteristic Description
CSI signal conversion converts the digital signal output by the controller into the trigger pulse signal required by the rectifier bridge (30V/500V level)
Pulse triggered generation integrated pulse trigger board (PTB) function, precise control of thyristor/IGBT conduction angle
Excitation current closed-loop control combined with PID algorithm to regulate the excitation current of the generator rotor and maintain stable terminal voltage
System protection monitoring real-time monitoring of overvoltage, undervoltage, overcurrent and other faults, supporting rapid protection actions
Dual power redundancy supports DC 9-36V dual power redundancy input, ensuring continuous operation in case of power failure
Hot swappable design supports live plugging, reducing downtime
Industrial grade reliability operating temperature -40 ° C~+75 ° C, protection level IP20
Remote maintenance supports Ethernet remote diagnosis, parameter modification, and firmware upgrade
Complete Comparison Table of UA D215 Series
Material number, model, voltage level, application scenario
3BHE02284R0101 UA D215 A101 15V, 500V low-voltage low-power excitation
3BHE026284R0102 UA D215 A102 15V, 1000V medium voltage medium power
3BHE026284R0104 UA D215 A104 30V, 500V ⭐ This model (medium voltage standard power)
3BHE026284R0105 UA D215 A105 30V, 1000V high voltage medium power
3BHE026284R0106 UA D215 A106 30V, 1500V ultra-high voltage high power
3BHE051993R0001 Adapter Plate - UA D215 → UA D209 Adapter Plate
application field
Specific applications in the field
Excitation control of synchronous generators for thermal power/hydropower/nuclear power to maintain stable terminal voltage
Accurate excitation control of large motors in industries such as steel, paper, and chemical for industrial motor excitation
Renewable energy wind power and photovoltaic grid control to enhance grid flexibility
DCS/SCADA integration supports protocols such as Modbus TCP/IP, Profibus DP, IEC 61850, etc
Association module (UNITOL 6000 system)
Material number, model, and function
3BHE022291R0101 PC D230 Excitation Regulator Measurement Board (CCM)
3BHE025541R0101 PC D231 B CCI Converter Control Interface
3BHE041343R0102 PC D530 A102 Communication Control Measurement (Standard Controller)
3BHE023784R2030 PP D113 B01-20 AC800PEC Controller
3BHE023126R0020 AF D242 A CCP Converter Control Panel
