HONEYWELL CC-TDIL01  模拟量输入输出端子板通常根据CPU所带的I/O点数的规模分为微型PLC、小型PLC、中型PLC、大型PLC、PC插卡式PLC以及PC兼容的PLC。各种规模分类标准如附表所示。

一套典型的PLC通常包括CPU模块、电源模块和一些输入/输出模块，这些模块被插在一块背板上。如果配置增加，可能会包括一个操作员界面、监控计算机、通讯模块、软件以及一些可选的特殊功能模块。可编程控制器不仅容易安装，占用空间小，能源消耗小，带有诊断指示器可以帮助故障诊断，而且可以被重复使用到其它的项目中去。尽管有PLC的功能，如运行速度、接口种类、数据处理能力已经获得了很大的提高，但PLC一直保持了其最初设计的原则，那就是简单至上的原则。

·HONEYWELL CC-TDIL01  模拟量输入输出端子板采用新的先进的微处理器和电子技术达到快速的扫描时间;·小型的、低成本的PLC，可以代替四到十个继电器;

·高密度的I/O系统，以低成本提供了节省空间的接口;

·基于微处理器的智能I/O接口扩展了分布式控制能力，典型的接口如PID，网络，CAN总线，现场总线，ASCII通信，定位，主机通讯模块和语言模块（如BASIC，PASCALC）等;

HONEYWELL CC-TDIL01  模拟量输入输出端子板·包括输入输出模块和端子的结构设计改进，使端子更加集成；

·特殊接口允许某些器件可以直接接到控制器上，如热电偶、热电阻、应力测量、快速响应脉冲等；

·外部设备改进了操作员界面技术，系统文档功能成为了PLC的标准功能。

以上这些硬件的改进，导致了PLC的产品系列的丰富和发展，使PLC从最小的只有10个I/O点的微型PLC，到可以达到8000点的大型PLC，应有尽有。这些产品系列，用普通的I/O系统和编程外部设备，可以组成局域网，并与办公网络相连。整个PLC的产品系列概念对于用户来说，是一个非常节约成本的控制系统概念。

与硬件的发展相似，PLC的软件也取得了巨大的进展，大大强化了PLC的功能:

·PLC引入了面向对象的编程工具，并且根据国际电工委员会的IEC61131-3的标准形成了多种语言;

· 小型PLC也提供了强大的编程指令，并且因此延伸了应用领域;

·高级语言，如BASIC，C在某些控制器模块中已经可以实现，在与外部通讯和处理数据时提供了更大的编程灵活性;

·梯形图逻辑中可以实现高级的功能块指令，可以使用户用简单的编程方法实现复杂的软件功能;

·诊断和错误检测功能从简单的系统控制器的故障诊断扩大到对所控制的机器和设备的过程和设备诊断;

·浮点算术可以进行控制应用中计量、平衡和统计等所牵涉的复杂计算;

·数据处理指令得到简化和改进, 可以进行涉及大量数据存储、跟踪和存取的复杂控制和数据采集和处理功能。
