Woodward 9907-006 主同步器和负载控制 具有同步器功能

【产品详情】

9907-006 主同步器和负载控制 （MSLC） 模块是一种多功能工具，具有同步器功能、实用负载传感器、用于导入/导出的负载水平控制器和主处理控制器，由 Woodward Inc 制造，9907-006 装置在设计和功能方面具有多项优势，例如减少了同步器模块和负载之间的接线量以及自动加载控制装置。

9907-006 装置中安装了许多功能，无需任何冗余传感器模块，如 PT、CT 和 MOP 装置。能够执行的丰富功能的一个例子包括但不限于可调功率因数控制、多功能可调上限和下限警报以及数字通信网络。

当您操作控制器并需要检查 MSLC 装置的电源是否正确时，您应该将电压设置为最小值，即 18 Vdc，然后您应该为控制器通电并确保自检菜单中的结果 0 相当于 49。

9907-006 设计有一套操作规范，例如电源进气口。所需的电源是 8 到 32 伏的连续直流电。9907-006 装置的电压检测输入采用 120 V/AC 开放式 Delta PT 配置，具有三相公用总线和单相发电机总线。9907-006 的频率输入范围为 45 至 66 赫兹。9907-006 型号符合 UL 和 cUL 标准。

Woodward 9907-006 主同步器和负载控制 具有同步器功能

【英文介绍】

The 9907-006 Master Synchronizer and Load Control (MSLC) module is a multi-function tool with synchronizer function, utility load sensor, load level controller for import/export, and master processing controller, manufactured by Woodward Inc. Available through a variety of new or used refurbished inventory from AX Control Inc. The 9907-006 device offers several advantages in terms of design and function, such as a reduction in the amount of wiring between the synchronizer module and the load and an automatic loading control.

Many functions are installed in the 9907-006 device without any redundant sensor modules, such as PT, CT and MOP devices. An example of the rich functionality that can be performed includes, but is not limited to, adjustable power factor control, multi-function adjustable upper and lower limit alarms, and digital communication networks.

When you operate the controller and need to check that the power supply of the MSLC device is correct, you should set the voltage to the minimum, which is 18 Vdc, then you should power the controller and make sure that the result 0 in the self-test menu is equivalent to 49.

The 9907-006 design has a set of operating specifications, such as power intake. The power required is 8 to 32 volts of continuous direct current. The voltage detection input for the 9907-006 unit is in a 120 V/AC open Delta PT configuration with a three-phase common bus and a single-phase generator bus. The 9907-006 has a frequency input range of 45 to 66 Hz. Models 9907-006 comply with UL and cUL standards.
