GE Fanuc IC697MDL252 分立式输入模块 具有输入电路

【产品详情】

技术规格

额定电压： 12 伏交流电

输入数量： 32 个输入（4 个隔离组，每组 8 个）

输入电流： 10毫安

所需电流： 0.30 安培

频率： 47 至 63 赫兹

直流电源： 不

 IC697MDL252分立式输入模块是GE Fanuc的产品。该模块属于 GE 系列 90-70。该模块的一些显着功能包括 4 个单独的组，每组 8 个输入点，总共 32 个点。它具有 20 毫秒的输入滤波时间，并且还与接近开关兼容。它以 12 伏交流电压运行，可与各种输入设备配合使用，例如限位开关、按钮、选择开关以及电子 2 线或 3 线接近开关。由于IC697MDL252输入模块具有隔离的输入点，每个输入点位于不同的交流电源相位上，因此它具有符合 IEC 标准 1 类要求并具有电流-电压特性的阻性输入。该模块具有 LED 指示灯，显示逻辑/PLC 电路侧每个输入点的开/关状态。指示器位于模块顶部。

GE Fanuc IC697MDL252 系列 90-70 输入模块是自动调谐的，从而确保其最终更换为相应的模块类型。该模块的操作员可以在不使用 DIP 开关或跳线的情况下配置输入和输出基准。此配置是通过 Windows 编程软件或 MS-DOS 软件完成的，该软件通过以太网 TCP/IP 或 SNP 端口在 Windows NT 或 Windows 95 上运行。设备上已安装配置功能软件。GE Fanuc IC697MDL252输入模块具有输入电路，可提供足够的电流，以保证开关设备的可靠稳定运行。它在导通状态下具有 10 毫安的输入电流，并且在关断状态下也可接受最大 2 毫安的泄漏电流，而无需接通。

GE Fanuc IC697MDL252 分立式输入模块 具有输入电路

【英文介绍】

Technical specification

Rated voltage: 12 volts AC

Number of inputs: 32 inputs (4 isolation groups, 8 per group)

Input current: 10 MA

Required current: 0.30 amps

Frequency: 47 to 63 Hz

Dc power supply: No

The IC697MDL252 discrete input module is a product of GE Fanuc. This module belongs to the GE series 90-70. Some of the notable features of the module include 4 separate groups of 8 input points each for a total of 32 points. It has an input filtering time of 20 milliseconds and is also compatible with proximity switches. It operates at 12 volts AC and can be used with a variety of input devices, such as limit switches, buttons, select switches, and electronic 2-wire or 3-wire proximity switches. Since the IC697MDL252 input module has isolated input points, each located at a different AC power supply phase, it has resistive inputs that meet the requirements of IEC standard Class 1 and have current-voltage characteristics. The module has an LED indicator that shows the on/off status of each input point on the logic /PLC circuit side. The indicator is located at the top of the module.

GE Fanuc IC697MDL252 Series 90-70 input modules are automatically tuned, thus ensuring their eventual replacement with the appropriate module type. The module's operator can configure input and output benchmarks without the use of DIP switches or jumpers. This configuration is done via Windows programming software or MS-DOS software, which runs on Windows NT or Windows 95 via Ethernet TCP/IP or SNP ports. The configuration software has been installed on the device. The GE Fanuc IC697MDL252 input module has an input circuit that provides sufficient current to ensure the reliable and stable operation of the switchgear. It has an input current of 10 MA in the on-state and can also accept a leakage current of up to 2 mA in the off state without being switched on.

GE Fanuc IC697MDL252 分立式输入模块 具有输入电路
