IC660HHM501 手持显示器 手持式监视器

【产品详情】

IC660HHM501是GE Fanuc制造的硬件。该电子设备是手持显示器（HHM），是Genius产品系列的一部分。它使用户能够监控总线上任何设备的 I/O 数据、诊断、总线扫描时间、总线上所有设备的描述、全局数据地址、总线上 CPU 的内存数据。 此外，该IC660HHM501还可用于硬件配置、故障清除、I/O 强制和总线选择。

它还允许设置安全性，以限制和管理对此手持式监视器（HHM）的不同信息和功能的访问。

HHM 是执行调试、维护和故障排除活动的便捷设备。它可以直接访问I/O块，模拟和强制CPU寄存器内的离散和模拟数据。

该IC660HHM501具有LCD显示屏，能够显示四（4）行信息，每行最多可以显示十六（16）个字符。这为用户提供了读数和信息。作为交互方式，IC660HHM501 HHM 配有二十 （20） 个按键密封薄膜键盘，由功能键、十进制键和操作键组成。这些提供的键盘允许用户输入适当的命令。该 HHM 还配备了一个按键开关，以防止对某些功能进行不必要的访问，具体取决于所选的限制。为了操作此 HHM，需要通过其电源输入端口提供外部电源电压。适当的电源电压为 115VAC 或 230VAC。此外，提供的电池组也可用于为该 HHM 供电。

模块的键盘由功能键、十进制键和操作键组成，提供可靠的操作。

IC660HHM501手持显示器配有电池组，无需连接电源即可运行长达 6 小时。它已通过跌落测试，其中它从 4 英尺的高度跌落到混凝土地板上。可以为手持显示器单独购买的一些可选配件是外部 HHM 连接器，可以在 genius Bus 上提供永久 HHM 连接、230 伏交流额定电源适配器、额外的 HHM 键和电池充电器。该模块可以使用提供的金属安装支架安装在面板后面。如果以这种方式安装，用户必须安装一个额外的 D-shell 连接器，该连接器也随模块提供。IC660HHM501手持式监视器是一种可靠的操作员界面设备，用于显示任何连接设备的 I/O 数据。此数据包括总线数据、诊断数据、CPU 的内存数据、总线扫描时间和全局数据地址。

IC660HHM501 手持显示器 手持式监视器

【英文介绍】

The IC660HHM501 is hardware manufactured by GE Fanuc. The electronic device is a Handheld display (HHM), part of the Genius product family. It enables users to monitor I/O data for any device on the bus, diagnostics, bus scan times, descriptions of all devices on the bus, global data addresses, and memory data for cpus on the bus. In addition, the IC660HHM501 can be used for hardware configuration, troubleshooting, I/O enforcement, and bus selection.

It also allows you to set up security to restrict and manage access to different information and functions of this handheld monitor (HHM).

The HHM is a convenient device for commissioning, maintenance and troubleshooting activities. It has direct access to I/O blocks, analog and forced discrete and analog data within CPU registers.

The IC660HHM501 has an LCD display capable of displaying four (4) lines of information with up to sixteen (16) characters per line. This provides the user with readings and information. As an interactive mode, the IC660HHM501 HHM is equipped with a twenty (20) key-sealed thin-film keyboard consisting of function keys, decimal keys, and action keys. These provide keyboards that allow the user to enter appropriate commands. The HHM is also equipped with a key switch to prevent unnecessary access to certain functions, depending on the selected restrictions. In order to operate this HHM, an external power supply voltage needs to be supplied through its power input port. The appropriate supply voltage is 115VAC or 230VAC. In addition, the supplied battery pack can also be used to power the HHM.

The module's keyboard consists of function keys, decimal keys and operation keys to provide reliable operation.

The IC660HHM501 handheld display is equipped with a battery pack and can operate for up to 6 hours without connecting to a power source. It has passed drop tests, in which it fell from a height of 4 feet to a concrete floor. Some optional accessories that can be purchased separately for handheld displays are external HHM connectors that provide a permanent HHM connection, a 230-volt AC rated power adapter, additional HHM keys, and a battery charger on the genius Bus. The module can be mounted behind the panel using the provided metal mounting bracket. If installed in this way, the user must install an additional D-shell connector, which is also supplied with the module. The IC660HHM501 handheld monitor is a reliable operator interface device for displaying I/O data from any connected device. This data includes bus data, diagnostic data, CPU memory data, bus scan times, and global data addresses.

IC660HHM501 手持显示器 手持式监视器
