531X102CCHAEM1 电阻和超过35个电阻网络阵列组成

【产品详情】

531X102CCHAEM1是用于工业应用的GE驱动器和工业系统的电路板组件。几十年来，通用电气生产了各种各样的驱动和驱动部件。

531X102CCHAEM1具有支架，允许添加两个辅助板。这些支架连接到电路板附近的两个垂直引脚连接器，这有助于这些辅助板之间的通信，当安装时，和主板。主板有一个额外的四个垂直引脚连接器和两个垂直引脚头。电路板有超过15个跳线开关和几个晶体管。晶体管被放置在电路板表面周围。

531X102CCHAEM1在电路板上共有8个电位器。其中六个被放置在一个垂直位置的板上。最后两个电位器并排放置，靠近电路板的一个角落。该电路板有大量的电容器，通常由聚酯乙烯基制成，尽管少数电容器由电解材料制成。它由电阻和超过35个电阻网络阵列组成。电路板也有多个电感器。电路板上的集成电路包括振荡芯片、八进制总线收发器和四路2输入OR门。单板有6个LED指示灯。每一个led都是红色的，并且都有单独的标签。

531X102CCHAEM1是工厂在每个角落钻孔安装选项。电路板上标有VA-4、VDC、FR00/0和F31X102CCHCBG1等代码。有关该板的更多信息，处理说明和安装程序可以在用户指南和参考零件号的数据表中找到。

531X102CCHAEM1 电阻和超过35个电阻网络阵列组成

【英文介绍】

The 531X102CCHAEM1 is a circuit board assembly for GE drivers and industrial systems for industrial applications. For decades, GE has produced a wide variety of drives and drive components.

The 531X102CCHAEM1 has a stand that allows the addition of two auxiliary boards. These brackets are connected to two vertical pin connectors near the circuit board, which facilitates communication between these auxiliary boards, when installed, and the motherboard. The motherboard has an additional four vertical pin connectors and two vertical pin heads. The board has more than 15 jumper switches and several transistors. Transistors are placed around the surface of the circuit board.

531X102CCHAEM1 has a total of 8 potentiometers on the circuit board. Six of them are placed on a board in a vertical position. The last two potentiometers are placed side by side, near a corner of the board. The board has a large number of capacitors, usually made of polyester vinyl, although a small number of capacitors are made of electrolytic materials. It consists of resistors and a network array of more than 35 resistors. The circuit board also has multiple inductors. The integrated circuit on the board includes an oscillator chip, an octal bus transceiver, and a four-way 2-input OR gate. The board has 6 LED indicators. Each led is red and has a separate label.

The 531X102CCHAEM1 is a factory drilling installation option at every corner. The board is marked with codes such as VA-4, VDC, FR00/0 and F31X102CCHCBG1. More information about the board, processing instructions, and installation procedures can be found in the user Guide and data sheets for reference part numbers.

531X102CCHAEM1 电阻和超过35个电阻网络阵列组成

【其他型号推荐】

【常见问题】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

无论您对库存，价格，故障排除还是其他方面有任何疑问，我们都能满足您的需求。请致电我们，填写我们的表格，或向我们发送电子邮件-任何适合您的方式。期待您的回音！
