GE IC200MDD840 组合式分立式输入输出模块

【产品详情】

IC200MDD840 是艾默生自动化 VersaMax 产品系列的一部分，前身为 GE 智能平台 （GE IP）。该模块专门用于组合 I/O 模块，具有嵌入式分立式输入和输出电路，例如十 （10） 个正逻辑 24 VDC 输入和十二 （12） 个 A 型或常开 （N.O.） 触点输出。该模块的最大背板电流消耗为 375 mA。

输入通道排列在两 （2） 组中，每组十 （10） 个输入通道。输入特性包括 0-30 VDC 和 24 VDC 标称电压的输入电压兼容性;导通状态电压为 +15 至 +30 VDC;关断状态电压为 0 至 0.5 mA;典型开/关信号转换延迟为0.5 ms（最大值），输入阻抗为10k欧姆（最大值）。输入通道具有可配置的滤波时间，可用于电子和机械噪声输入通道，从而消除假阳性和假阴性信号。这些滤波时间包括 0 ms、1.0 ms 和 0.7 ms，默认配置为 1.0 ms。

继电器输出通道排列成两 （2） 组，每组六 （6） 个通道。触点输出的额定电流最小为每点 10mA;每个模块最大 8.0A;2.0 安培，5 至 265VAC，最大用于阻性负载;2.0 安培，5 至 30 VDC，最大值用于电阻负载，0.2 安培，用于 31 至 125 VDC，与电阻一起使用时最大值。该模块的继电器类型为固定线圈，移动电枢，采用银合金触点类型。

IC200MDD840分立式I/O模块是GE智能平台/GE Fanuc的产品，是Versamax产品系列的成员，提供12个继电器输出和20个分立输入。GE Fanuc IC200MDD840模块的输入分为 2 行，每行 10 个输入。这些输入点有源极类型和正逻辑类型，但它们通常从连接的设备接收电流，然后在公共端返回电流。此外，该分立式 I/O 模块上的 12 个继电器输出分为 2 组，每组 6 个点，每组可承受高达 8 安培的电流。该模块的尺寸约为 4.3 x 2.63 x 1.956 英寸，但这些测量值不包括载体或配接连接的高度。

GE Fanuc IC200MDD840 分立式 I/O 模块直接从安装在机架上的背板获取电源，但对于所有输出负载，都需要外部电源。它采用 24 伏直流输入电压和 0 至 125 伏直流电和 0 至 265 伏交流电的输出电压运行。当 I/O 打开时，IC200MDD840模块的额定电流为 2.0 至 5.5 毫安，而在关闭状态下，其额定电流为 0 至 0.5 毫安。该模块通过PLC系统中的网络接口单元（NIU）和中央处理器（CPU）进行处理。然而，IC200MDD840模块没有像内部保险丝那样的保护措施，也不支持通道间隔离。

GE IC200MDD840 组合式分立式输入输出模块

【英文介绍】

The IC200MDD840 is part of Emerson Automation's VersaMax product family, formerly known as the GE Intelligence Platform (GE IP). This module is specifically designed for combined I/O modules with embedded discrete input and output circuits, such as ten (10) positive logic 24 VDC inputs and twelve (12) Type A or normally open (N.O.) contact outputs. The maximum backplane current consumption of this module is 375 mA.

The input channels are arranged in two (2) groups of ten (10) input channels each. Input features include input voltage compatibility for 0-30 VDC and 24 VDC nominal voltages; The on-state voltage is +15 to +30 VDC; The off state voltage is 0 to 0.5 mA; The typical on/off signal conversion delay is 0.5 ms (maximum) and the input impedance is 10k ohms (maximum). The input channels have configurable filtering times that can be used for both electronic and mechanical noise input channels to eliminate false positive and false negative signals. These filter times include 0 ms, 1.0 ms, and 0.7 ms, with 1.0 ms as the default.

The relay output channels are arranged in two (2) groups of six (6) channels each. The rated current of contact output is at least 10mA per point; Max. 8.0A per module; 2.0 amps, 5 to 265VAC, maximum for resistive loads; 2.0 amps, 5 to 30 VDC, maximum for resistive loads, 0.2 amps, 31 to 125 VDC, maximum when used with resistors. The relay type of the module is fixed coil, moving armature and silver alloy contact type.

The IC200MDD840 discrete I/O module, a product of GE Intelligent Platform /GE Fanuc and a member of the Versamax product family, offers 12 relay outputs and 20 discrete inputs. The input of the GE Fanuc IC200MDD840 module is divided into 2 lines with 10 inputs per line. These input points have an active pole type and a positive logic type, but they usually receive current from the connected device and then return current at the common end. In addition, the 12 relay outputs on the discrete I/O module are divided into 2 groups of 6 points each, each of which can withstand currents of up to 8 amps. The module measures approximately 4.3 x 2.63 x 1.956 inches, but these measurements do not include the height of the carrier or fitting connection.

The GE Fanuc IC200MDD840 split I/O module draws power directly from the rack-mounted backplane, but an external power supply is required for all output loads. It operates with an input voltage of 24 volts DC and an output voltage of 0 to 125 volts DC and 0 to 265 volts AC. When I/O is on, the IC200MDD840 module is rated from 2.0 to 5.5 mA, while when I/O is off, it is rated from 0 to 0.5 Ma. The module is processed by the network interface unit (NIU) and the Central processing unit (CPU) in the PLC system. However, the IC200MDD840 module does not have protection like the internal fuse and does not support inter-channel isolation.
