GE  IC694MDL732 正逻辑输出模块 该模块带有 8 个输出

【产品详情】

技术规格

额定电压： 12/24 伏直流

# 输出数量： 8 （1组）

频率： 不适用

输出电流： 每点 0.5 A

输出电压范围： 12 至 24V 直流电（+20%， -15%）

功耗： 50V 总线时 5 mA

IC694MDL732输出模块是由GE发那科自动化公司设计的正逻辑输出模块。该模块带有 8 个输出，这些输出包含在单个组中，每个输出都能够从用户公共和正总线向负载提供电流。该输出设备需要连接在负电源总线和模块输出之间，以便有效。GE Fanuc自动化IC694MDL732正逻辑输出模块可以轻松插入RX3i通用背板，并且可以安装在机架的任何插槽中，不会出现任何问题或错误。操作现场设备的电源需要由用户从外部电源提供。

GE Fanuc Automation IC694MDL732正逻辑输出模块在 12 至 24 伏直流电的额定电压下工作，它为背板和框架接地提供隔离电压，即 250 伏交流连续和 1500 伏交流电 1 分钟。该模块还具有每点 0.5 安培和每共点最大 2 安培的输出电流。GE发那科自动化IC694MDL732正逻辑输出模块能够进行热插拔。这种机制使模块在机架中的安装变得容易。该模块有 8 个 LED，用于显示每个输出的状态。该模块的开和关响应时间最长为 2 毫秒。该模块不包括任何保护功能，例如保险丝或断路器。它的正面带有蓝色标签，表明它是一个低压模块。

GE  IC694MDL732 正逻辑输出模块 该模块带有 8 个输出

【英文介绍】

Technical specification

Rated voltage: 12/24 V DC

# Output quantity: 8 (1 group)

Frequency: Not applicable

Output current: 0.5A per point

Output voltage range: 12 to 24V DC (+20%, -15%)

Power consumption: 5 mA for 50V bus

The IC694MDL732 output module is a positive logic output module designed by GE Fanuc Automation. The module comes with 8 outputs, which are contained in a single group, each capable of providing current from the user common and positive bus to the load. The output device needs to be connected between the negative power bus and the module output in order to be effective. The GE Fanuc Automation IC694MDL732 positive logic output module can be easily inserted into the RX3i universal backplane and can be installed in any slot of the rack without any problems or errors. The onsite devices are powered by an external power supply.

The GE Fanuc Automation IC694MDL732 positive logic output module operates at a voltage rating of 12 to 24 volts DC, which provides isolation voltage for backplane and frame grounding, i.e. 250 volts AC continuous and 1500 volts AC for 1 minute. The module also has an output current of 0.5 amps per point and a maximum of 2 amps per common point. The GE Fanuc Automation IC694MDL732 positive logic output module is hot-swappable. This mechanism makes it easy to install the module in the rack. The module has 8 leds that display the status of each output. The module has an on and off response time of up to 2 milliseconds. The module does not include any protective features such as fuses or circuit breakers. It has a blue label on the front indicating that it is a low-voltage module.

GE  IC694MDL732 正逻辑输出模块 该模块带有 8 个输出
