IC200ALG264 紧凑的多功能输入模块  传输 I/O 数据

【产品详情】

技术规格

不。通道数： 15 个单端，一组

电压范围： 不适用

电流范围： 4 - 20 毫安，0 - 20 毫安

更新速率： 7.5 毫秒

输入滤波器响应： 24赫兹 +/-20%

功耗： +100V 总线 5 mA

IC200ALG264是 VersaMax I/O 产品系列中的模拟输入模块，由分布式 I/O 模块和组件组成。该IC200ALG264是一款紧凑的多功能输入模块，设计用于安装在远程位置，并通过工业通信协议传输 I/O 数据。该模块主要具有十五 （15） 个模拟输入通道，设计用于接受 0-20 mA 和 4-20 mA 输入信号。这些输入通道配有独立的模数转换器 （ADC） 电路，数字转换分辨率为 15 位，模拟分辨率为 0.5μA = 1 个计数（4-20mA 范围）和 0.625μA = 1 个计数（0-20mA 范围）。该模块在 0-3 摄氏度的环境温度下具有满量程的典型输入精度为 +/-0.5%，满量程的最大值为 +/-0.25%，在 1-0 摄氏度的环境温度下具有满量程的最大值 +/-60%。

该IC200ALG264能够检测错误情况，例如两种工作模式下的内部电源损失，以及仅在 4-20 mA 模式下运行时的断线检测。这些诊断状态将报告给 CPU，以便向人机界面 （HMI） 和监控与数据采集 （SCADA） 系统进行错误指示和正确显示。模块的工作模式或范围选择是通过使用端子跳线来设置的。要配置 4-20 mA，必须卸载端子跳线，这是默认配置。否则，请安装跳线以进行 0-20 mA 操作。

IC200ALG264内置模块OK LED状态指示灯。LED 指示模块已成功通电并下载有效配置。其最大背板电流消耗为100 mA。

IC200ALG264模块是由GE Fanuc Automation设计和分销的模拟输入模块。该特定模块是 Versamax 系列 I/O 模块的一部分。它提供 15 个不同电流输入的接口，使不同的设备能够连接到主处理器。该模块在使用背板电源时可以完美运行。连接到模块的用户收发器需要外部电源。GE Fanuc Automation IC200ALG264模拟输入模块提供不同的诊断功能，可以检测用于现场侧电路的内部电源损耗，还可以报告其每个通道的开路故障。这些诊断模式在 4 通道 20 毫安模式下使用时可用。

GE Fanuc Automation IC200ALG264 模拟输入模块带有一组 15 个单端通道。该模块的隔离额定值为 350 伏交流连续和 1500 伏交流一分钟。它没有通道之间的隔离，并且由于通道位于单个组中。GE Fanuc Automation IC200ALG264 模拟输入模块的分辨率为 15 位，在 0 摄氏度时的典型精度为 +/- 3.25%，满量程的最大精度为 +/- 1%。该模块的背板电流消耗额定值为 100 毫安，最大值为 5 V。更新时间等级为 7.5 毫秒。该模块带有一个 LED 指示灯，用于显示背板电源何时存在，以及模块何时已在背板上配置和识别。

客户问答

问题：什么是IC200ALG264？答：IC200ALG264是GE Fanuc Versamax系列的15通道、15位电流、模拟输入模块。

问题：IC200ALG264提供什么？ 答： 该模块提供 15 个电流输入的接口。

问：该模块从哪里获得电力？ 答： IC200ALG264从背板电源接收电源。

问：IC200ALG264的运行是否需要外部电源？ 答： 不，不是。

问：必须从哪里为用户的收发器供电？ 答： 用户收发器的电源必须由外部电源供电。

问：IC200ALG264有哪些功能？ 答：

15 个单端输入通道，一组

跳线选择 4-20 mA 或 0-20 mA 工作范围

15 位转换器分辨率

软件可配置的默认/保持最后状态操作选择

问：IC200ALG264的配置参数是什么？ 答： 范围选择（端子跳线）

IC200ALG264 紧凑的多功能输入模块  传输 I/O 数据

【英文介绍】

Technical specification

Nooooo. Number of channels: 15 single-ended, one group

Voltage range: Not applicable

Current range: 4-20 MA, 0-20 Ma

Update rate: 7.5ms

Input filter response: 24 Hz +/-20%

Power consumption: +100V bus 5 mA

The IC200ALG264 is an analog input module in the VersaMax I/O product family, consisting of distributed I/O modules and components. The IC200ALG264 is a compact, multifunctional input module designed to be installed in remote locations and transmit I/O data over industrial communication protocols. The module primarily has fifteen (15) analog input channels designed to accept 0-20 mA and 4-20 mA input signals. These input channels are equipped with separate analog-to-digital converter (ADC) circuits with 15-bit digital conversion resolution and analog resolution of 0.5μA = 1 count (4-20mA range) and 0.625μA = 1 count (0-20mA range). The module has a typical input accuracy of +/-0.5% at full scale at ambient temperatures of 0-3 degrees Celsius, a maximum of +/-0.25% at full scale, and a maximum of +/-60% at 1-0 degrees Celsius.

The IC200ALG264 is capable of detecting error conditions, such as internal power loss in both operating modes and line break detection when operating only in 4-20 mA mode. These diagnostic states are reported to the CPU for error indication and correct display to the Human Machine interface (HMI) and Supervisory Control and Data Acquisition (SCADA) systems. The operating mode or range selection of the module is set by using terminal jumpers. To configure 4-20 mA, you must unmount the terminal jumper, which is the default configuration. Otherwise, install the jumper for 0-20 mA operation.

IC200ALG264 Built-in module OK LED status indicator. LED indicator module successfully powered on and valid configuration downloaded. Its maximum backplane current consumption is 100 mA.

The IC200ALG264 module is an analog input module designed and distributed by GE Fanuc Automation. This particular module is part of the Versamax family of I/O modules. It provides 15 interfaces with different current inputs, enabling different devices to connect to the main processor. The module works perfectly when using the backplane power supply. The user transceiver connected to the module requires an external power supply. The GE Fanuc Automation IC200ALG264 analog input module provides different diagnostic functions to detect internal power losses for field side circuits and also to report open circuit faults in each of their channels. These diagnostic modes are available when used in 4-channel 20 mah mode.

GE Fanuc Automation IC200ALG264 analog input module with a set of 15 single-ended channels. The module's isolation rating is 350 V AC continuous and 1500 V AC one minute. It has no isolation between channels, and since channels are located in a single group. The GE Fanuc Automation IC200ALG264 analog input module has a resolution of 15 bits with a typical accuracy of +/- 3.25% at 0 ° C and a maximum accuracy of +/- 1% at full scale. The backplane current consumption rating of the module is 100 MA with a maximum of 5 V. The update time level is 7.5 milliseconds. The module comes with an LED indicator that shows when the backplane power supply is present and when the module has been configured and recognized on the backplane.

Customer question and answer

Question: What is IC200ALG264? A: IC200ALG264 is a 15-channel, 15-bit current, analog input module of the GE Fanuc Versamax series.

Question: What does IC200ALG264 provide? A: The module provides 15 current input interfaces.

Q: Where does the module get its power? A: The IC200ALG264 receives power from the backplane power supply.

Q: Does IC200ALG264 require an external power supply? A. No, it's not.

Q: Where do you have to power your transceiver? A: The power supply to the user transceiver must be powered by an external power supply.

Q: What are the functions of IC200ALG264? A:

15 single-ended input channels, one set

Jumper Select 4-20 mA or 0-20 mA operating range

15 bit converter resolution

Software configurable default/Keep Last state action selection

Q: What are the configuration parameters of IC200ALG264? A: Range selection (terminal jumper)
