GE IC694PWR321 电源模块 可提供3路输出

【产品详情】

技术规格

标称额定电压： 120/240 伏交流电或 125 伏直流

输入电压范围： 85 至 264 VAC 或 100 至 300 VDC

输入功率： 90 VA 带交流交流或 50 W（带 VDC）

负载能力： 30 瓦

模块类型： 扩展电源

背板支持： 仅限远程基地

 IC694PWR321电源模块由GE Fanuc在RX3i PacSystem系列中作为PLC电源设计和制造。它可以用于任何RX3i PLC，因为它与所有GE RX3i CPU兼容。IC694PWR321电源模块的额定电压为 120/240 伏交流电和 125 伏直流电。它被设计为串行扩展设备，需要安装在其主机PLC的串行背板上，特别是在最左侧的插槽中。IC694PWR321电源模块的额定电流为 2 安培，它可以提供高达 30 瓦的功率，除非它以 5 伏直流输出电压运行，在这种情况下，它只能提供 15 瓦的功率。它不支持负载共享冗余功能。

GE Fanuc RX3i IC694PWR321扩展电源模块可提供3路输出。第一路输出是 5 伏直流输出，第二路输出是 24 伏直流继电器输出，可为输出继电器模块上的电路供电，第三路输出是 24 伏直流隔离输出，可为连接到额定直流电压为 24 伏直流的输入模块的现场设备供电。IC694PWR321电源模块在 85 至 264 伏交流电或 100 至 300 伏直流电的输入电压下运行。其绿色“PWR”LED 在打开且电源和电平稳定时亮起，绿色“OK”LED 在整个 PLC 正常运行时亮起，绿色“RUN”LED 在 PLC 以运行模式运行时亮起。

GE IC694PWR321 电源模块 可提供3路输出

【英文介绍】

Technical specification

Nominal voltage: 120/240 volts AC or 125 volts DC

Input voltage range: 85 to 264 VAC or 100 to 300 VDC

Input power: 90 VA with AC or 50 W with VDC

Load capacity: 30 watts

Module type: Expansion power supply

Backplane support: Remote base only

The IC694PWR321 power module is designed and manufactured by GE Fanuc as a PLC power supply in the RX3i PacSystem family. It can be used with any RX3i PLC because it is compatible with all GE RX3i cpus. The rated voltage of the IC694PWR321 power module is 120/240 volts AC and 125 volts DC. It is designed as a serial expansion device and needs to be installed on the serial backplane of its host PLC, particularly in the leftmost slot. The IC694PWR321 power module is rated at 2 amps, and it can deliver up to 30 watts of power unless it is operating at 5 volts DC output voltage, in which case it can only deliver 15 watts of power. It does not support load sharing redundancy.

The GE Fanuc RX3i IC694PWR321 Expansion power module provides three outputs. The first output is a 5 volt DC output, the second output is a 24 volt DC relay output that powers the circuit on the output relay module, and the third output is a 24 volt DC isolated output that powers field equipment connected to an input module with a rated DC voltage of 24 volts DC. The IC694PWR321 power module operates at an input voltage of 85 to 264 volts AC or 100 to 300 volts DC. The green "PWR" LED lights up when it is turned on and the power and level are stable, the green "OK" LED lights up when the whole PLC is running normally, and the green "RUN" LED lights up when the PLC is running in running mode.

GE IC694PWR321 电源模块 可提供3路输出
