IC660TSA100 GE 端子组件 电流模拟 I/O 模块

【产品详情】

GE Fanuc IC660TSA100端子组件是 I/O 块的端子组件。IC660TSA100端子组件与IC660BBA100 I/O 块兼容。

GE Fanuc IC660TSA100终端组件是GE Fanuc的I/O模块的终端组件，其目录号为IC660BBA100。该 I/O 模块是具有 2 个输出和 4 个输入的电压和电流 I/O 模块。IC660BBA100模块是一个 115 伏交流额定电压和电流模拟 I/O 模块。与IC660BBA100块和IC660TSA100端子组件兼容的电子组件具有目录号IC660EBA100。I/O 块的重量约为 4 磅，尺寸为 224.4 x 33.4 x 39.1 毫米。IC660BBA100 I/O 块上提供 LED，它们是“I/O 已启用”和“设备正常”LED。块的块到块的隔离额定值以及作为其一部分的IC660TSA100端子组件为 1500 伏，散热额定值为 6 瓦。

IC660BBA100模块以及扩展IC660TSA100端子组件的标称工作电压为 98 至 132 伏交流电。最大额定功耗为 10 VA。IC660BBA100模块可以接受 47 到 63 赫兹的线路频率。I/O 模块的电源压降时间为 1 个周期。绝对精度为满量程的 +/-0.2%。最大精度为满量程的 +/-0.5%。在存在强RF干扰的情况下，精度可能会降低到满量程读数的+/-0.5%加上读数的0.5%。25 摄氏度时的热漂移在 50 伏范围内为 10 毫伏，在 25 伏范围内为 5 毫伏，在 100 至 4 毫安范围内为 20 毫安。IC660BBA100上的每个电路都可以提供或接受以下范围内的信号：0 至 5 伏直流、0 至 10 伏直流、4 至 20 毫安或 1 至 5 伏直流、-10 至 10 伏直流电和 -5 至 5 伏直流电。

IC660TSA100 GE 端子组件 电流模拟 I/O 模块

【英文介绍】

The GE Fanuc IC660TSA100 terminal assembly is the terminal assembly of the I/O block. The IC660TSA100 terminal assembly is compatible with IC660BBA100 I/O blocks.

The GE Fanuc IC660TSA100 terminal component is the terminal component of the I/O module of GE Fanuc. The directory number is IC660BBA100. The I/O module is a voltage and current I/O module with 2 outputs and 4 inputs. The IC660BBA100 module is a 115 volt AC rated voltage and current analog I/O module. Electronic assemblies compatible with IC660BBA100 blocks and IC660TSA100 terminal assemblies have the catalog number IC660EBA100. The I/O block weighs about 4 pounds and measures 224.4 x 33.4 x 39.1 mm. Leds are provided on the IC660BBA100 I/O block, which are "I/O Enabled" and "Device Normal" leds. The block to block isolation rating of the block and the IC660TSA100 terminal assembly as part of it are 1500 volts with a heat dissipation rating of 6 watts.

The IC660BBA100 module and the extended IC660TSA100 terminal assembly have nominal operating voltages from 98 to 132 volts AC. Maximum rated power consumption is 10 VA. The IC660BBA100 module can accept line frequencies from 47 to 63 Hertz. The power voltage drop time of the I/O module is one cycle. Absolute accuracy is +/-0.2% of full scale. The maximum accuracy is +/-0.5% of full scale. In the presence of strong RF interference, accuracy may be reduced to +/-0.5% of the full scale reading plus 0.5% of the reading. The thermal drift at 25 degrees Celsius is 10 millivolts in the 50 volt range, 5 millivolts in the 25 volt range, and 20 milliamps in the 100 to 4 mA range. Each circuit on the IC660BBA100 can provide or receive signals in the following ranges: 0 to 5 volts DC, 0 to 10 volts DC, 4 to 20 MA or 1 to 5 volts DC, -10 to 10 volts DC, and -5 to 5 volts DC.

IC660TSA100 GE 端子组件 电流模拟 I/O 模块
